Designer Auditorium Seats

Product Description

 Saryu gulmohar

This is a push back chair  with very stylish p.P handles and poly filled back . The back is filled with recron fibre (polfill ) which is indeed soft and comfortable……..

The base foam is p.U foam with 45 density .

This chair is very popular in vip row seating /  home theather etc.

Size ..

 Height ………… 41 inches

Width …………… 23 inches

 Length ……….. 28 inches

 Push back movement ….. 4 to 5 inches ( as required)

Further details:

 We are engaged in offering designer auditorium seats with the following specification :
 sheet metal frame:-

  foot is made of cr deep draw sheet of the size 330-â85â1.66mm with hole distance of 255mm between two fasteners.

     this foot is made of single piece of c.R. Sheet with deep drawing dies. The foot pipe is of dimension 38mm-78â3mm.

  the back frame & base frame are made of c.R. Pipe of the size ( 19x 2mm)t.H of erw tube is : 30748 1976 grade I. These frames are embedded (not pasted) to p.U. Foam. In precise frames are inbuilt in foam.

  the back & base frame supports zigzag spring for swinging comfort.

·        p.U foam:- polyurethane foam used is close cell formation, high pressure with cfc free quality.

    density = 50+ 5kg/m3 jisk 6401

  hardness = cusion = 120 (+30/-20) newton,backrest = 80 (+30/-10) newton

    constant compression set(max :- -13%) jisk 6401)

·        p.U foam measurement:

    base cushion: l b th = 465x475x130 (in mm)

   backrest: l b th = 690x450x100 (in mm)

  the foam must have a depth of 45mm at shoulder area and depth gradually decreases to 15mm at bottom.

 p.U foam happens to be the most critical part of the chair, hence it is very important to maintain density, hardness & overall quality of the foam.

 powder coating:- the frame is well powder coated with prior 7 tank

 phosphating treatment & 70 to 80 microns of powder coating.

cloth :- fire retardant cloth with 3mm high density lamination (cost rs. 200p/mt) the cloth is well pasted with p.U. Foam.

plastic cover: - back foam is covered by special plastic cover made of p.P.C.P material (poly propylene co-polymer).

   this 5mm thick p.P.C.P plastic back cover adds to elegance & provides protection from mishandling .

 row numbers & asile light :- row no. Are well placed on p.P.C.P. Cover of base. The side panel should support row no. & asile lights for illumination.

 p.U. Handle:- handles are of p.U. (integral foam) without cup holders. V.I.P. Chairs / front rows can have special aluminum pressure die casted handle with p.U. Saddles and cup holders. The aluminum handle are well powder coated and colour of the handle should match to the fabric of the chair as decided by architect.

moving mechanism ;- this chair has synchronous movement of back & base. The mechanism is popularly called scissor mechanism. The sliding movement can be achieved as desired by the customer and space available. (4" to 6"). The base can be manually tip-up.

Other measurement of the chair :-

• height of the chair = 1040 mm
• width of the chair = 585 mm
• length of the chair = 710 mm
• height of the handles = 600 mm
• length of the handle = 470 mm
• width of the handle = 75 mm
•  sliding movement = 115 mm

Warranty: - three years warranty for complete chair.

After sale service: - 6 free services during warranty period of three years.
